This newest addition to the Lumenera line of digital cameras is a game changer for microscope users! It provides users with phenomenal color reproduction, high dynamic range, a large field of view and fast preview speeds that are needed for brightfield applications. It also offers the high sensitivity and low noise required for fluorescence imaging... It's two cameras in one!

Built on Sony’s 6.0 MP EXview HAD II CCD sensor, this camera offers extremely high dynamic range, 4.54 x 4.54 um pixels and very low noise. Lumenera has achieved a remarkably low 6.5 electron read noise, while blazing at the industry's fastest speed on this sensor at 27 frames per second.

With 2x2 binning, there is a fourfold increase in sensitivity while providing a 1.5 MP (1376x1096) resolution. Full resolution 6.0 MP images are sent to a host computer at up to 27 frames per second (fps) over the plug and play USB 3.0 connection. The INFINITY3-6UR delivers outstanding image quality for challenging low light applications such as fluorescence, including those in the NIR region.

Need a larger field of view for your application? To maximize the sensitivity of the new INFINITY3-6UR, Lumenera used a new larger 1” format Sony ICX694 sensor.  With an approximately 50% larger active surface area than the ICX285 with 2/3" optical format, this high resolution camera achieves a more-than-4x increase in resolution with a less-than-2x decrease in effective sensitivity.


Click here to view larger version of the image below:


The INFINITY3-6UR is the ideal solution for most microscopy applications due to its 6.0 MP resolution, excellent color reproduction, speed and sensitivity needed for low-light applications.

This unique camera is indeed a game changer: Striking color reproduction, low noise, free analysis software, USB3.0 with backward compatibility for USB 2.0 and software upgrades available at no charge - what's not to love?



· 27 fps at 6.0 megapixel, 46 fps (binned 2x2), 75 fps at VGA (640 x 480)

· Industry leading Sony EXview HAD ll sensor technology with high QE

· Color or monochrome ICX694 CCD sensor with 1" optical format providing a resolution of 2752 x 2192 using 4.54 x 4.54 μm pixels

· High-speed USB 3.0 interface for ease of installation on any computer

· GPIO for control of peripherals and synchronization. 1 optically isolated output, 1 optically isolated input and 2 configurable I/O ports

· 128 MB of onboard memory for frame buffering results in reliable image delivery for demanding systems

· Select 8 and 14-bit pixel data modes


DC Imaging, LLC


Microscopes – Imaging Products - Service - Training

Office: 7561 Easy St   Unit C   Mason, OH  45040

  Phone: (513) 404-6299    Fax: (206) 984-1858


6.0 MP, 1" CCD Color Camera, USB 3.0, Infinity Analyze

$  5,495.00


6.0 MP, 1" CCD Monochrome Camera, USB 3.0, Infinity Analyze
