BA310 Digital Microscopes

USB2.0 2048 X 1536 pixel live output

Digital Siedentopf Head 30o inclined (Built-in 1/2" 3.0 Megapixel Imaging Chip)

Widefield eyepieces WF10X /20mm

Reversed Quintuple nosepiece

CCIS EF-N Plan Achromat Objectives 4X, 10X, 40X S, 100X S-Oil

Coaxial coarse and fine focusing adjustment

Built in low position coaxial mechanical stage

Focusable & Centerable 0.9 N.A. Abbe condenser

Switching power supply 100-240V (CE)

Quartz Halogen 6V/30W Koehler Illumination

USB 2.0 PC connection

Motic Images Plus 2.0 multi-language version software for PC, and English for OSX



BA310 Digital   from $2500

BA310 Digital PRO  from $3450  (includes 5MP (2592 X 1944) camera, Motic Images Advanced 3.2 software)

BA210 Digital Microscope



USB2.0 2048 X 1536 pixel live output

Digital Siedentopf Head 30o inclined (Built-in 1/2" 3.0 Megapixel Imaging Chip)

Widefield eyepieces WF10X/20mm

Reversed Quadruple nosepiece

CCIS EF-N Plan Achromat Objectives 4X, 10X, 40X S, 100X S-Oil

Coaxial coarse and fine focusing adjustment

Built in low position coaxial mechanical stage

Focusable 1.25 N.A. Abbe condenser

Switching power supply 100-240V (CE)

Quartz Halogen 6V/20W Illumination

USB 2.0 PC connection

Motic Images Plus 2.0 multi-language version software for PC, and English for OSX



BA210 Digital    from $1970



Contact for Regional Discounts

BA Series Digital LCD Microscopes

Convert the BA Series (210, 310 or 410) microscopes to a Digital Station with the Moticam 1080 BMH, making it an ideal solution for laboratories, universities, teachers, doctors, veterinaries or anyone who wishes to effortlessly see and share digital images. The HDMI connection guarantees 1080p live images with high quality and without losing frame rate. The camera allows capturing images of 5MP and full HD videos with its remote control. The images/videos are stored directly on the SD card, allowing you to work without a computer. However, you can connect the camera with a USB cable to AV-image devices or a computer. Images Plus 2.0 software is included in the package.



Pricing for BA410 with Moticam 1080 BMH begins at $4400; BA310 with 1080 BMH at $3000, and BA210 with 1080 BMH at $2675.

DC Imaging, LLC



Microscopes – Imaging Products - Service - Training

Office: 7561 Easy St   Unit C   Mason, OH  45040

  Phone: (513) 404-6299    Fax: (206) 984-1858

Email: info@dcimaging2000.com

Panthera L Digital Binocular   from $2,850.00

Binocular head Siedentopf type 30° inclined, 360° rotating with SmartCam 5 mp camera

Wide field high eyepoint eyepiece N-WF10X/22mm with diopter adjustment on both eyepieces and rubber eyecups

SmartMicroscope function with ImagingOnDevice system

HDMI, WiFi, USB and Ethernet outputs

Reversed quintuple revolving nosepiece, coded

Plan Achromat objectives UC 4x, 10x, 40x S, 100x S-oil

Coaxial coarse and fine focusing adjustment with tension adjustment

Built in low position rackless coaxial stage (Right-hand control)

Focusable Abbe condenser N.A. 09/1.25 with iris diaphragm and slot

3W LED Koehler illumination with intensity control LED indicator with Motic LightTracer function





DIGITAL MICROSCOPES
